AHD™ 2nd Generation

All-time great technology

The world's first mass-produced analog HD transmission technology powered by Nextchip, AHD™, has become the de-facto standard, truly the most powerful analog HD transmission technology adopted by OEMs and tiers in Korea, China, Europe, and Japan.

Building on the success of the previous generation, the second-generation AHD™ is now unveiled — once again reshaping the analog video market by meeting diverse demands such as 60fps and ultra-high resolution.

  • Resolution

    Up to 3840x2160@15p

  • Video Input

    4-lane MIPI CSI-2 RX
    24bit Parallel Video Interface
    BT.656 / BT.1120
    RGB888 / 565
    YUV422 8/10bits

  • Video Out

    AHD(TM) analog video standard encoding
    720p 25/30/50/60fps, 1080p 25/30/50/60fps
    and up to 4Mp 25/30fps or 8Mp 15fps format encoding
    NTSC/PAL

  • Size

    8mm x 8mm
